Channels, Ducts and Lids for Agricultural Applications
Robust solutions for farm infrastructure
Our range of high-quality precast concrete channels, ducts, and lids are designed to aid the agricultural sector for farming applications.
Our products provide durable, versatile, and cost-effective solutions for housing utility services and managing drainage on farms.
Our channels, ducts and lids offer:
Exceptional durability
Engineered to withstand harsh agricultural environments and heavy machinery use.
Versatile applications
Suitable for housing electric cables, gas pipes, water lines and much more.
Easy installation
Quick to deploy, reducing on-site construction time.
Low maintenance
Concrete’s longevity ensures minimal upkeep overtime.
Enhanced safety
Protects underground services from accidental damage.
Improved accessibility
Removable lids allow for easy access for maintenance and repairs.
Agri-Applications
Utility Management
Safely house and protect power cables, telecom lines and various types of pipework.
Drainage Solutions
Ideal for managing surface water and implementing sustainable drainage systems (SuDS).
Livestock Areas
Durable troughs suitable for various types of livestock.
Product Range

Ducts
Code | Drawing | Channel dimensions mm | Unit weight |
||||||
A | B | C | D | E | F | G | |||
5107 | 1500 | 300 | 300 | 390 | 470 | 314 | 454 | 320kg | |
5059 | 2000 | 600 | 450 | 575 | 850 | 700 | 850 | 945kg | |
1196 | 1000 | 450 | 450 | 575 | 655 | 475 | 655 | 390kg | |
1603 | 1000 | 600 | 320 | 445 | 910 | 700 | 850 | 440kg | |
1606 | 1000 | 600 | 620 | 745 | 910 | 700 | 850 | 605kg | |
1755 | 1000 | 730 | 520 | 660 | 1070 | 730 | 1000 | 670kg | |
1757 | 1000 | 700 | 770 | 910 | 1100 | 700 | 990 | 885kg | |
1050 | 1000 | 1000 | 520 | 660 | 1320 | 1060 | 1240 | 740kg | |
1075 | 1000 | 960 | 770 | 910 | 1350 | 1060 | 1240 | 955kg | |
1010 | 1000 | 930 | 1020 | 1160 | 1380 | 1060 | 1240 | 1220kg | |
1012 | 1000 | 1000 | 1200 | 1325 | 1450 | 1100 | 1350 | 1460kg |
Lids
Code | Drawing | Lid dimensions mm | Unit weight |
|||
H | I | J | K | |||
5107 | 1500 | 475 | 105 | 95 | 182kg | |
1197 | 1000 | 655 | 135 | 120 | 220kg | |
1601 | 1000 | 920 | 160 | 145 | 350kg | |
1701 | 1000 | 1070 | 160 | 145 | 420kg | |
1001 | 1320 | 1320 | 160 | 145 | 520kg |
